Key Features
• Industry standard low profile Eighth-brick
58.4 x 22.7x 9.6 mm (2.30 x 0.89 x 0.38 in)
• High efficiency, typical 96 % at 48Vin, 12 Vout, half load
• 2250 Vdc input to output isolation
• Pre-bias start up
• Optional Baseplate
• Optional SMD version
• Meets safety requirements according to IEC/EN/UL 60950-1
• MTBF 8.9 Million hours
General Characteristics
• Input under voltage shutdown
• Monotonic start-up
• Remote control
• Output over voltage protection
• Over temperature protection
• Output short-circuit protection
• Highly automated manufacturing ensures quality
• ISO 9001/14001 certified supplier
