PKU4913D系列--33.02 x 22.86 x 11.30 mm--1/16砖,100W

品牌: Flex
功率: 100W
尺寸: 33.02 x 22.86 x 11.30 mm  1/16砖
产品详情

Key Features

• Industry standard low profile 1/16 brick

    33.02 x 22.86 x 11.30 mm (1.3 x 0.9 x 0.44 in)

• High efficiency, typical 94.6% at 48Vin, full load

• 2250 Vdc input to output isolation

• Pre-bias start up

• Optional Baseplate

• Meets safety requirements according to IEC/EN/UL62368-1

• MTBF 13.88 Million hours

General Characteristics

• Monotonic start-up

• Remote control

• Output over voltage protection

• Over temperature protection

• Over current protection

• Highly automated manufacturing ensures quality

• ISO 9001/14001 certified supplier
